    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    Ask Lasest Price
    Brand Name : TOP
    Model Number : 320
    Certification : ISO
    Supply Ability : 10 Set/Sets per Month Resin Impregnation Line
    Price : $120,000.00/sets 1-1 sets
    • Product Details
    • Company Profile

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    I. Features

    1. It has industrial standard modularized design, handy human-computer dialog and rich information reminder in

    Chinese and English.

    2. The high precision gauging roller ensures the gluing precision and surface quality of the impregnator.;

    3. The high precision reticular roller(gravure coater) with precision scrubber secures the preciseness of glue coating;

    4. The advanced and reliable tension control system works effectively in controlling the strain of the paper tape

    operation;

    5. Both the transmission roller and the hot-air blower come with high efficient energy saving inverter control to

    reach low energy consumption, synchronous linear stability and low paper breakage;

    6. The double photoelectric synchronous motor controls and adjusts deviation to have the deviation adjustment

    stability and the stead operation of paper;

    7. The paper cutter is available with the coding technology of preciseness and accurateness and being capable

    of setting the cutting length at will;

    8. The temperature of the drying chamber comes with PID high-precise control and the exact-accurate

    temperature control;

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    II. Technical Parameters

    1.

    Main raw material

    28-170g/cbm

    2

    Max work width

    1850mm

    3

    Mechanical speed

    0-50m/min (frequency control and adjustable)

    4

    Width of roller surface

    2200mm

    5

    Diameter of paper reel

    ≤1000mm

    6

    Weight of Paper reel

    max 2000kg

    7

    Paper core diameter

    76mm

    8

    Impregnating material

    UF/MF/PF

    9

    Glue quantity

    50%-270%

    10

    Volatilization content

    6.0%-7.5%

    11

    Production speed

    decided by glue type and paper density

    12

    noise:

    80DB(A)

    13

    working height of paper:

    1200mm

    14

    Heat mode

    thermal oil

    15

    Work temperature:

    100-180℃(by technology request)

    16

    overall size

    About 57000mmX3500mmX4200mm (Length ×Width ×Height )

    17

    total weight

    about 65 ton

    18

    total power:

    about 75Kw

    19

    Heat consumption

    ≤800,000 Kcal/h

    20

    Compressed air:

    0.6MPa,5m3/h

    21

    Cooling water

    6 m3/h, 20℃, 0.4 MPa

    22

    Gluing precision:

    ≤±2%

    23

    Volatility precision:

    ≤±0.2%

    24

    Temperature control precision:

    ≤±2°C

    25

    Length error of cutting final paper

    ±1mm

    26

    Power supply:

    380VAC 50Hz

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 ProductMelamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 ProductMelamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    III. Packaging & shipping

    Certification

    SGS,FSC,CE,ISO9001:2000

    Price Terms

    FOB/CIF/CFR

    Payment

    T/T, 100% irrevocable L/C at sight

    Package

    Seaworthy packing

    Remarks

    High quality and inexpensive price,your ideal choice.

    Melamine Paper Impregnation Machine Resin Impregnation Line 2000*2000*2000 Product

    IV. Our service

    Pre-sale service:

    1) Free consultation on any aspect of equipment/production line;

    2) The professional materials & flow chart;

    3) Offering the reasonable plan & proposal as per customer's specific requirements;

    4) Related reception for equipment inspection;

    In-sale service:

    1) Oversea equipment installation & commissioning;

    2) Personnel training;

    After-sale service:

    1) 24 hours online service;

    2) Video for equipment maintenance;

    3) One year quality warranty;
