Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Ask Lasest Price
Brand Name :	TOP
Model Number :	TPA
Supply Ability :	100 Piece/Pieces per Month
Price :	$4,999.00/pieces >=1 pieces

Add to Cart

Product Details
Company Profile

Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Product Description

Stainless Steel Rotary Drum Vacuum Filter from Chinese manufacturer

Product Description
The Stainless Steel Irragation Rotary Drum Filter for waste water is a mechanical, self-cleaning filter that works with gravity to prevent particle fragmentation. The filtering process of Drum Screen Filter is very simple, yet very efficient and reliable due to its overall design and operation. Drum Filters are designed with few moving parts to ensure a long life with low operating/maintenance cost.

Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Working Principle

The polluted water inputs the drum filter through the water inlet pipes, flows into the boxes, and then into the interior of the filtering drum. The filtering drum is covered with a V-slot micro mesh, all particles bigger than the filter mesh will stay inside the drum filter.

The waste particles will slowly block the filter mesh, makes it hard for the water through the mesh, which leads to a lower water level in the clear water chamber of the filter. Once the water level dropped to a minimum level-indicated by sensor-the controller starts the washing process. The process contains the rotation of the filter drum by a geared motor and multiple nozzles spraying water with high pressure to the outside of the filter mesh. The waste clogged the filter mesh is flushed into the waste tray, and then leaves the filter by wastewater discharge through waste outlet.
V-slot Features
Slot Section

The Continuous slot screens are made of V-shape wire or wedge shape wire around an internal array of longitudinal support rods. Each jointpoint of these wire is fusion welded, the V or wedge shaped profile wire wraps around the support rods over the full length of the screen creating a continuous slot opening. Therefore the screen allows water or oil to enter the well freely in ample quantities while keeps the majority of sand and gravel out of the well at the same time.

Continuous slot: support rods and longitudinal wire makes an opening which significantly increase the available opening area, and allow better access to the water flow.

High open area: reduce the water level, thus to save energy consumption. Meanwhile, high open area can make the groundwater enter the screen much slower than other filtration apparatus, which can avoid sand from entering screen due to high pressure, hereby lowering pump wear down.

High Strength: It takes stainless steel as main raw material, then is welded at high temperature, which guarantee high strength to bear big water pressure, hereby it has long life span.
Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Structure Options

V-Shape slots: V-Shape wire gives inwardly widening V-shape slots
Features
The Stainless Steel Irragation Rotary Drum Filter have following advanced features:

1. Made for landscape ponds and aquaculture
2. Compact structure easy installation
3. Filtration capacity: from 16-420 m3 of water per hour
4. Self-cleaning and automatic backwash
5. High quality and environmentally-friendly materials
6. Very low noise
7. Gravity& pump mode
8. Option for integrated UV lamp with double function
9. Easy operation and low maintenance
10.Long life time
Specifications

Model			TP-600	TP-800	TP-1000	TP-1200	TP-1400	TP-1600	TP-1800	TP-2000
Drum Diameter			600	800	1000	1200	1400	1600	1800	2000
Mesh length			650	850	1000	1200	1400	1500	1650	1850
Input tube OD			159	219	219	273	273	325	325	325
High water lvl H3			400	520	670	820	950	1100	1250	1350
Install angle			35°
Channel depth H2			600-800	700-1000	900-1200	1100-1400	1200-1600	1400-1800	1600-2000	1800-2100
Waste outlet H1			1000mm
Min install lengthA			3000	3300	3600	4000	4300	4700	5000	5300
Max water treat m³/h	Slot mm	0.5	80	135	235	315	450	585	745	920
		1	125	215	370	505	720	950	1205	1495
		2	190	330	555	765	1095	1440	1830	2260
		3	230	400	680	935	1340	1760	2235	2755
		4	235	430	720	1010	1440	2050	2700	3340
		5	250	465	795	1105	1575	2200	2935	3600

Operation mode
Pump mode and gravity mode

Control unit of this titled rotary drum filter is equipped with two operation modes: gravity mode and pump mode. According to the different needs of customers, the operation mode can be selected conveniently by a switch installed on the control unit box.

Packaging & Shipping
Plastic film or wooden boxes package or as per customers' requirements.
Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Company Information
Top Machinery is located i Chengdu, being with convenient traffic, developed communication, vast territory and a good space for development. We are professional manufacturer and exporter of accessories for water, oil, gas and environmental industries. The products mainly including filter elements like Johnson screen mesh , water well screen, V shaped wire welded screen pipe, strainer pipe, spiral screen tube, wire-wrap screen pipe, wedge wire screen tube, mine screen mesh, arc screen, flat wedge wire panel, as well as automatic washing filter, backwashing filter, drum filter, ion exchanger, etc. Since the company established, we insist on good quality, making the business range extend continually.

All of production lines are provided on a turnkey basis including design, program, installation, commission, and complete technology transfer and personnel training, which are backed by our extensive experience. Complete spare parts/components and engineering services are provided according to customers' requirements. We sincerely hope to establish cooperation with you. We sincerely welcome all clients to contact us for details.
topindustry.en.made-in-china.com

Production Facility:
With R&D team, we can design and manufacture the machine according to customer requirements.
Water Filtration Aquaculture Indoor Ras Drum Filter for Fish Farming/Pond

Client Visit:
Welcome to visit our factory anytime.

Packaging & Shipping:
Wooden Package with high quality to protect your machine.
